CASIO FX-501P / FX-502P
Type
ManufacturerCasio
Introduced1978
Calculator
Entry modeInfix
Precision12 digits mantissa, ±99 exponent
Display type
Display size10 + 3 Digits
Programming
Programming language(s)Keystroke(fully merged, Turing complete)
Memory register11 (FX-501P), 22 (FX-502P)
Program steps128 (FX-501P), 256 (FX-502P)
Interfaces
Portsone vendor specific
Connects toCompact Cassette via:
Other
Power supply2×'G13' or 2×'LR44'
Power consumption0.0008 W
Weight141 g, 5 oz
Dimensions15.24×7.6×1.2 cm, 6'×3'×½'
  1. Casio 10 Year Battery Replacement
  2. Casio 10 Year Battery Watches
  3. Casio 10 Year Battery Life
  4. Casio 10 Year Battery Digital Sport Watch

The FX-501P and FX-502P were programmable calculators, manufactured by Casio from 1978/1979.[citation needed] They were the predecessors of the FX-601P and FX-602P.

It is likely that the FX-501P/502P were the first LCD programmable Calculators to be produced as up until 1979 (and the introduction of the HP-41C) no manufacturer had introduced such a device.

Arithmetic[edit]

The FX-502P series use the algebraic logic as was state of the art at the time.

  1. Turns out Casio offers a handful of wristwatches with '10 year battery life'. The claim is that thanks to 'an advanced technology' the battery life in those watches is extended to ten years.
  2. Ten years is a long time and that is exactly why we used a battery that lasts just as long. Equipped with E-Data memory and 4 multi-function alarms, you will never miss a step.
  3. Watch is not included only band, Bezel,Gasket,Battery,Box and Cradle. Not suitable for any other models. Fit that is a DINOSAER Casio has stopped making. See details - Genuine Casio Watch Band,Bezel,O-Ring,Battery,Box G-Shock DW-5600E-1V DW-5600E.
  4. Product description The sporty style of a digital watch, combined with the dependability of a 10-year battery makes this watch perfect for any time. With the added features of an alarm, stopwatch and hourly time signal, you’ll never lose track of time. Black 10 Year Battery Casual.

Display[edit]

The FX-501P and FX-502P featured a single line 7-segment liquid crystal display with 10 digits as main display. An additional 3 digits 7-segment display used to display exponents and program steps when entering or debugging programs and 10 status indicators. The display was covered with a yellow filter, supposedly to prevent ultra-violet radiation damage to the unstable (at the time) Liquid Crystal compound.[citation needed]

From Casio, a leader in wrist technology, comes a new smart power series, featuring multi-mission LCD with LC Analog and 10 Year Battery. F201WA-1AV $ 14.95.

Casio 10 Year Battery

Programming[edit]

The programming model employed was key stroke programming by which each key pressed was recorded and later played back. On record multiple key presses were merged into a single programming step. All operations fitted into one program step.[1]

The FX-501P could store 128 steps, with 11 memory registers. The FX-502P had twice that capacity with 256 steps and 22 memory registers.

Conditional and unconditional jumps as well as subroutines were supported. The FX-502P series supported 10 labels for programs and subroutines called P0 .. P9. Each program or subroutine could have up to 10 local labels called LBL0 .. LBL9 for jumps and branches.

The FX-501P and FX-502P supported indirect addressing both for memory access and jumps and therefore the programming model could be considered Turing complete.

Since the FX-501P and FX-502P only employed a seven-segment display each program step was represented by a special 2-digit codes made up of the digits 0 .. 9 and the character C, E, F and P. The calculator came with a special overlay[2] so the user did not need to memorize the mapping between code and actual command.

What differentiated the FX-501 / FX-502P from its competitors was that programming was retained in a battery-buffered memory when the calculator was turned off.

Programming example[edit]

Here is a sample program that computes the factorial of an integer number from 2 to 69. For 5!, the user would type 5P0 and get the result 120. The whole program is only 9 bytes long.

Key-codeDisplay-codeComment
P0P0call the program with the P0 key
Min0C6-00stores the value in register 0
101starts with 1
LBL0F0-00label for the loop
*E1multiply
MR0C7-00with M0
INVDSZFF-01Decrements M0 and skips next command if M0=Zero
GOTO0F1-00Go to LBL0
=E5end of loop, the machine has calculated 1×n×(n1)××2×1=n!{displaystyle 1times ntimes (n-1)times cdots times 2times 1=n!}
Watch

Interface[edit]

Casio FA-1
Connects toFX-502P series and FX-602P series

Compact Cassette via one of:

  • Line-Out: 3.5 mm TRS connector
  • Mic-In: 3.5 mm TRS connector
ManufacturerCasio
Introduced1979
TypeCompact Cassette Interface

Casio 10 Year Battery Replacement

Casio 10 year battery digital sports watchYear

The FX-501P and FX-502P used the FA-1 to store program and data to Compact Cassette using the Kansas City standard. The FA-1 also enabled the calculators to generate musical notes.[2]

The FX-501P was used on the 1981 song Pocket Calculator by electronic music group Kraftwerk.[3]

References[edit]

Casio 10 Year Battery Watches

  1. ^FX-602P Token list - the FX-502P series only employed the standard plane.
  2. ^ abcasio fx-501p with programming overlay
  3. ^'Pocket Calculator by Kraftwerk'. Songfacts. Retrieved 1 May 2020.

Casio 10 Year Battery Life

External links[edit]

Casio
  • FX-501P and FX-502P on casio.ledudu.com maintained by ledudu.
  • FX-501P and FX-502P on RS-Key maintained by Viktor Toth.
  • Casio FX-501P and Casio FX-502P on Voidware

Casio 10 Year Battery Digital Sport Watch

Retrieved from 'https://en.wikipedia.org/w/index.php?title=Casio_FX-502P_series&oldid=991912779'
